SEED HAWK® 30 SERIES OPERATOR’S MANUAL 98
5.4 HYDRAULIC CYLINDERS
Inspect hydraulic cylinder seals and hose connections at cylinder fittings every 10 hrs or daily.
Tighten any loose fittings, FIGURE 5.3. Cylinder seals are replaceable. Contact a technician
trained in hydraulic maintenance and repairs if assistance is required for replacing cylinder
seals.
SEALS
HOSE FITTINGS
CYLINDER
FIGURE 5.3
