SEED HAWK® 30 SERIES OPERATOR’S MANUAL 54
4.18 MENU SETTINGS
The Setup Menu is accessed from the main screen
by pressing any Soft Key to bring up the Soft Key
Menu, then selecting Setup from the Soft Key
Selections.
Press the “Setup” key
The Menu Settings screen lists 12 choices:
1. MuxBus Sensor Setup: This is used to install and remove sensors that operate on the
MuxBus network. These include the ground speed sensor, the Fan sensors, the Bin Level
sensors, pressure and flow sensors.
NOTE: The VAR Controller listed is not used in this application.
NOTE: The pressure sensor listed as a MuxBus sensor is available but a different sensor than the
Packing Pressure sensor. That sensor is connected to the hydraulic drive control module and is
communicated on the CAN network. It is called Shank Pressure in the layout item select menu.
2. Global Settings: Use this menu selection to set
the units of measure, language, implement width,
the volume of the alarm, the backlight and
contrast of the screen, and the master switch
mode
FIGURE 4.37
FIGURE 4.38
