SEED HAWK® 30 SERIES OPERATOR’S MANUAL 64
4.22 METER CALIBRATION
4.22.1 PRE‐CALIBRATION
NOTE: All Meters on aircart must be individually calibrated. Calibrations must be done each
time a crop is changed. Calibration for the seed is done at the front hopper, on the left side
of the machine, and calibration for the fertilizer is done at the rear hopper, on the right side
of the machine.
Measure and record the weight of the empty calibration bag supplied.
CALIBRATION BAG WEIGHT:
_________________________
Once calibration bag is weighed, then attach the bag to the meter, SEE FIGURE 4.65. FIGURE 4.64 FIGURE 4.65
