SEED HAWK® 30 SERIES OPERATOR’S MANUAL 38
4.9.1 WITH SEED IN THE FRONT SEED HOPPER AND EMPTY REAR HOPPER
FAN ROTATION SPEED FLAP
30 SERIES 6M 30 SERIES 8M
SMALL SIZE SEEDS 2500 RPM 2500 RPM 100 % OPEN
CORN 3700 RPM 4000 RPM 100 % OPEN
4.9.2 WITH SEED IN FRONT SEED HOPPER AND FERTILIZER IN THE REAR HOPPER
FAN ROTATION SPEED FLAP
30 SERIES 6M 30 SERIES 8M
SMALL SIZE SEEDS 3700 RPM 4000 RPM 50 % OPEN
CORN 3700 RPM 4000 RPM 100 % OPEN
4.9.3 WITH SEED IN BOTH SEED HOPPERS
FAN ROTATION SPEED FLAP
30 SERIES 6M 30 SERIES 8M
CORN 3700 RPM 4000 RPM 100 % OPEN
4.9.4 FAN ALARMS
The alarm in the LOUP III monitor warning of too low of a rotation speed is best set for 500 rpm
below the pre‐set rotation speed, and the alarm warning of too high of a rotation speed is best
set for 500 rpm above the pre‐set rotation speed. REFER TO “4.23 ALARMS” ON PAGE 70.
