SEED HAWK® 30 SERIES OPERATOR’S MANUAL 88
4.28.6 MUD SCRAPER ADJUSTMENT
Ensure that the Pneumatic packer tire had a pressure of 10 to 15lbs. There is no adjustment to
the Semi‐pneumatic since there is no air pressure. Also ensure the gap between the packer tire
and the mud scraper is between the distances labeled in FIGURE 4.122. Be sure to check mud
scraper setting before seeding and every year to ensure proper gap between packer tire and
mud scraper.
Gap 1/16” to
1/8”
FIGURE 4.122
