SEED HAWK® 30 SERIES OPERATOR’S MANUAL 34
4.6 WINGING DOWN TOOLBAR
1. Make sure all opener shanks are up.
2. Engage the lever direction in the tractor cab that the GREEN banded hoses are hooked to,
this will allow the wings to unfold up into working position.
THIS GAUGE WILL READ PRESSURE
WHEN WINGING DOWN
FIGURE 4.5
FIGURE 4.4
