IAI America RCP2W-RA10C - Manual (Page 20)

14
RCP2
RA4R type
RA6R type
Grease supply port
(thin head screw)
Cable joint
connector
End plate
Reversing
bracket
Wire cover
Motor cover
Motor end cover
Aluminum frame
Rod
Rod tip adapter
Range of
T-groove
Motor side
Right
Left
Front
