94
13. Appendix
13.1.4 RCP2-RA6C
DETAIL: A
8 22
(25.4)
M14 s1.5
19
25
50
19
32
50
64 2 2
64
68 (4.8) 4
ST 52 112
L
11
30.5
42 6 4
ij
3
M14 s1.5
ME SE Home ME
6.5
10.5
2.6
8
A
Secure at least 100
13
75
(240)
Ƒ
M6
5
Brake Unit
0.5
63.5 64
112 72.5
With the Brake
4-M8 Depth 15
Dimensions for Accessory
Nut to Attach on Rod Tip
T-groove Effective Range
9.5 (Square block part)
Rod Diameter
F
30
Dimensions for Accessory
Square Nut to Attach on T-groove
(4 pieces attachment)
Cable Joint Connector
Ŷ'LPHQVLRQVIRUHDFK6WURNH
Stroke 50 100 150 200 250 300
Ɛ 138 188 238 288 338 388
L 250 300 350 400 450 500
Weight [kg] 3.1 3.6 4.1 4.6 5.1 5.6
ME : Mechanical End
SE : Stroke End
* The brake-equipped type is longer than the standard
type in 72.5mm and heavier in 0.9kg.
