Mounting sensor bracket XTPB V001 to pallet stop device XTPD U200 or
XTPD D35
Introduction
The sensor is not included in sensor bracket V001. If
nothing else is specified the instruction steps are valid
for both XTPD U200 and XTPD D35.
Tools
Instruction
Allen key 3 mm
Screwdriver
1 XTPD D35
Remove the cover with a screwdriver.
2 XTPD U200
Use the screws (2 x M4) to mount the sensor
bracket to the stop unit.
