FlexLink X85X (85 мм) Монтаж опорного кронштейна User Manual

Pre-requisites, Safety, Products

background image

The illustration may not always correspond exactly to ordered component.

PRE-REQUISITES

Recommended tools

Basic value, Torque for dimension

M5

M6

M8

M10

45 Nm / 398 lb.in.

24,5 Nm / 217 lb.in.

9 Nm / 80 lb. in.

4 Nm / 35 lb. in.

SAFETY

WARNING
At installation, maintenance
and service, make sure the
motor is shut off.

CAUTION
Due to heavy weight - 2
person lift, or mechanical

lift equipment.

10 - 25 kg

HEAVY WEIGHT

WARNING
Pinch Point

WARNING
The system must not be
operated without safety
equipment properly
mounted.

PRODUCTS

DOCUM

ENTATIO

N

5115332

24 Nm

5114999

5115001

5114998
