3 Notice the label Left and Right on the chain.

Mount the chain to the conveyor with similar
mark.

4 Insert the chain from below, with the nose for-

ward.

CAUTION! Make sure that you start feeding the
chain in the idler end unit and towards the driving
unit or it might lead to a chain damage.

5 Catch the chain and feed it via the idler end into

the conveyor. Repeat the same procedure with
the other chain.

6 Feed the chains into the conveyor until they

reach the drive wheel at the driving end.
