16 5113235
Lift and rotate module P11
Overview
Pos Name Designation Instruction
1 Pallet stop device XTPD U200 See page 38
2 Pallet stop device, damped XTPD D35 See page 40
3 Pallet stop device, damped XTPD D100 See page 42
4 Sensor bracket XTPB V001 See page 43
5 Sensor bracket XTPB V002 See page 45
6 Sensor bracket XTPB H001 See page 48
7 Mounting lift and rotate unit XTUR P11 See page 68
PW
PL
PW
PW
PL
PL
5
3
7
6
2
1
4
D = D00
D = D01
D = D02
