28 5113235
7 Feed the chains to the drive wheel and turn the
drive shaft until the chains are hanging a bit
below the conveyor.
CAUTION! Make sure that the chain enters the
drive wheel correctly. Risk for the plastic guides
to brake.
8 Use a pair of slip joint pliers to insert the pin half-
way into the chain link.
9 Join the chain endings. Make sure that the joint
ball has not been removed and re-assembled
upside down.
CAUTION! Wrongly positioned joint ball will lead
to chain damage when running the chain.
10 Press the pin through the chain. Use the pin
insertion tool.
Check rib down
