Adjust the position of the trolley so that the hook is hanging below the centerline of the beam.
Select L-dimensions according to rope reeving and beam flange from table below.
!
Tighten the nuts (2) and (3) to the correct tightening torque. Refer to the section
'Recommended tightening torques'.
6.6.1.1 Standard reeving (1 rope from drum)
Falling
ropes
B-dimension L1
L2
L3
L4
(mm.) Inch (mm.) Inch (mm.) Inch (mm.) Inch (mm.)
Inch
2 100-200
3.9-7.9
122 4,8 120 4,7 37 1,5 B/2-30
B/2-1.2
201-610
7.9-24 122 4,8 194 7,6 0
0 B/2-67 B/2-2.6
4 120-200
4.7-7.9
188.5 7,4 167 6,6 80 3,1 B/2-48
B/2-1.9
201-330
7.9-13
188.5 7,4 247 9,7 40 1,6 B/2-88
B/2-3.5
331-610
13-24
188.5
7,4 327
12,9 0 0 B/2-128
B/2-5
6 120-200
4.7-7.9
188.5 7,4 168 6,6 101 4 B/2-49 B/2-1.9
201-330
7.9-13
188.5 7,4 248 9,8 61 2,4 B/2-89
B/2-3.5
331-610
13-24
188.5
7,4 370
14,6 0 0 B/2-151
B/2-5.9
8 200-330
7.9-13 220 8,7 248 9,8 71 2,8 B/2-89
B/2-3.5
Single 331-450
13-17.7 220 8,7 316 12,4 37 1,5 B/2-124
B/2-4.9
Trolley 451-610 17.7-24 220
8,7
390 15,4
0
0
B/2-161 B/2-6.3
8 200-330
7.9-13
220 8,7 260 10,2 65 2,6 B/2-95 B/2-3.7
Bogey 331-450
13-17.7 220 8,7 316 12,4 37 1,5 B/2-124
B/2-4.9
Trolley 451-610 17.7-24 220
8,7
390 15,4
0
0
B/2-161 B/2-6.3
6.6.1.2 True vertical lift (2 ropes from drum)
Falling
ropes
B-dimension
L1
L2
L3
L4
(mm.) Inch (mm.) Inch (mm.) Inch (mm.) Inch (mm.) Inch
4 100-200
3.9-7.9
158 6,2 158 6,2 37 1,5 B/2-49
B/2-1.9
201-330
7.9-13 232 9,1 232 9,1 0
0 B/2-86 B/2-3.4
331-450
13-17.7
232 9,1 232 9,1 0
0 B/2-86 B/2-3.4
451-610
17.7-24
232 9,1 232 9,1 0
0 B/2-86 B/2-3.4
8 100-200
3.9-7.9
158 6,2 158 6,2 74 2,9 B/2-49
B/2-1.9
201-330
7.9-13 232 9,1 232 9,1 37 1,5 B/2-86
B/2-3.4
331-450
13-17.7
306 12 306 12,0 0
0 B/2-123
B/2-4.8
451-610
17.7-24
306 12 306 12,0 0
0 B/2-123
B/2-4.8
12
or
120-200
4.7-7.9
183 7,2 168 6,6 74 2,9 B/2-49
B/2-1.9
16 201-330
7.9-13 183 7,2 242 9,5 37 1,5 B/2-86
B/2-3.4
331-450
13-17.7
183 7,2 316 12,4 0
0 B/2-123
B/2-4.8
451-610
17.7-24
183 7,2 316 12,4 0
0 B/2-123
B/2-4.8
