243 Appendix B
B.2.7 ADAM-6052 16-ch Digital I/O Module
Address
0X
Ch Description Attribute Address 4X Ch Description Attribute
00001 0 DI Value Read 40001~40002 0 Counter/Frequency
Value
1
Read
00002 1 Read 40003~40004 1 Read
00003 2 Read 40005~40006 2 Read
00004 3 Read 40007~40008 3 Read
00005 4 Read 40009~40010 4 Read
00006 5 Read 40011~40012 5 Read
00007 6 Read 40013~40014 6 Read
00008 7 Read 40015~40016 7 Read
00017 0 DO Value R/W 40017~40018 0 Pulse Output
Low Level Width
2
R/W
00018 1 R/W 40019~40020 1 R/W
00019 2 R/W 40021~40022 2 R/W
00020 3 R/W 40023~40024 3 R/W
00021 4 R/W 40025~40026 4 R/W
00022 5 R/W 40027~40028 5 R/W
00023 6 R/W 40029~40030 6 R/W
00024 7 R/W 40031~40032 7 R/W
00033 0 Counter
Start(1)/
Stop(0)
R/W 40033~40034 0 Pulse Output
High Level Width
2
R/W
00034 Clear Coun-
ter(1)
Write 40035~40036 1 R/W
00035 Clear
Overflow
3
R/W 40037~40038 2 R/W
00036 DI Latch
Status
4
R/W 40039~40040 3 R/W
00037 1 Counter
Start(1)/
Stop(0)
R/W 40041~40042 4 R/W
00038 Clear Coun-
ter(1)
Write 40043~40044 5 R/W
00039 Clear
Overflow
3
R/W 40045~40046 6 R/W
00040 DI Latch
Status
4
R/W 40047~40048 7 R/W
00041 2 Counter
Start(1)/
Stop(0)
R/W
00042 Clear Coun-
ter(1)
Write 40049~40050 0 Set Absolute Pulse 5 R/W
00043 Clear
Overflow
3
R/W 40051~40052 1 R/W
00044 DI Latch
Status
4
R/W 40053~40054 2 R/W
00045 3 Counter
Start(1)/
Stop(0)
R/W 40055~40056 3 R/W
00046 Clear Coun-
ter(1)
Write 40057~40058 4 R/W
