219 Appendix A
3. Mapping the I/O data base into ADAM-6000 I/O modules.
1) In column A, note the TCP IP addresses for individual function areas.
2) In column B, list the I/O module’s product number.
3) In column C, enter the max # of I/O points available per module.
4) In column D, total the number of the I/O point you need.
5) In column E, calculate the total # of these modules that you will need.
6) In column F, enter the # of spare modules needed for future expansion.
7) In column G, enter the total # (Required + Spare) of these modules that
you need for these systems.
4. Implement the Modbus address in to the I/O table.
Table A.2: Summary Required Modules
ADAM-6000
IP Address
I/O Module
Product No. I/
O Points per
Module
Total I/O
Points
Required
I/O Module
Required
Spare I/O
Modules
Total I/O
Modules
