ADAM-6000 Series User Manual 120
Function Code 03/04
The function code 03 or 04 is used to read the binary contents of input
registers
Request message format for function code 03 or 04:
Example: Read Analog inputs #1 and #2 in addresses 40001 to 40002 as
floating point value from ADAM-6017 module
01 04 00 01 00 02
Response message format for function code 03 or 04:
Example: Analog input #1 and #2 as floating point values where
AI#1=100.0 and AI#2=55.32
01 04 08 42 C8 00 00 47 AE 42 5D
Function Code 05
Force a single coil to either ON or OFF. The requested ON/OFF state is
specified by a constant in the query data field. A value of FF 00 hex
requests it to be ON. A value of 00 00 hex requests it to be OFF. And a
value of FF FF hex requests it to release the force.
Request message format for function code 05:
Command Body
Station
Address
Function
Code
Start
Address
High Byte
Start
Address
Low Byte
Requested
Number of
Register
High Byte
Requested
Number of
Register
Low Byte
Command Body
Station
Address
Function
Code
Byte Count Data Data
Command Body
Station
Address
Function
Code
Coil
Address
High Byte
Coil
Address
Low Byte
Force Data
High Byte
Force Data
Low Byte
