4. When DI channel is configured as “High to low latch” or “Low to
high latch”, this bit will be 1 if the latch condition occurs. After
that, value of this bit will keep 1 until user writes 0 to this bit (clear
the latch status).
5. Decide how many pulses will be generated. When user writes 0 to
this bit, it will continuously generate pulse.
6. During the pulse generation, user can use this bit to generate more
pulses. For example, “Absolute pulse” is set as 100. During its gen-
eration, user can set “Incremental pulse” as 10. After the 100 pulses
are generated, the extra 10 pulses will continue to be generated.
7. Only for ADAM-6050
B.2.6 ADAM-6051/6051W
16-ch DI/O w/ Counter Module
Address
0X
Ch Description Attribute Address
4X
Ch Description Attribute
00001 0 DI Value Read 40001~
40002
0 Counter/Frequency
Value
1
Read
00002 1 Read 40003~
40004
1 Read
00003 2 Read 40005~
40006
2 Read
00004 3 Read 40007~
40008
3 Read
00005 4 Read 40009~
40010
4 Read
00006 5 Read 40011~
40012
5 Read
00007 6 Read 40013~
40014
6 Read
00008 7 Read 40015~
40016
7 Read
00009 8 Read 40017~
40018
8 Read
00010 9 Read 40019~
40020
9 Read
00011 10 Read 40021~
40022
10 Read
00012 11 Read 40023~
40024
11 Read
00013
12
7 Read 40025~
40026
12 Read
00014
13
7 Read 40027~
40028
13 Read
00017 0 DO Value R/W 40029~
40030
0 Pulse Output
Low Level Width
2
R/W
00018 1 R/W 40031~
40032
1 R/W
