Remarks:
1.
When channel cannot detect RTD signal, this bit register will be 1.
2.
User can configure High alarm value in the ADAM.NET utility.
When AI value is higher than High alarm value, this bit will be 1.
3.
User can configure the Low alarm value in the ADAM.NET utility.
When AI value is lower than the Low alarm value, this bit will be 1.
B.2.2 ADAM-6017
8-ch Analog Input Module
Address
0X
Channel Description
Attribute Address
4X
Channel Description Attribute
00017 0
DO
Value
R/W
00018
1
DO Value
R/W
00101 0
Reset
Historical
Max. Value
R/W 40001
0
AI
Value Read
00102 1
Reset
Historical
Max. Value
R/W
40002
1 AI
Value
Read
00103 2
Reset
Historical
Max. Value
R/W
40003
2 AI
Value
Read
00104 3
Reset
Historical
Max. Value
R/W
40004
3 AI
Value
Read
00105 4
Reset
Historical
Max. Value
R/W
40005
4 AI
Value
Read
00106 5
Reset
Historical
Max. Value
R/W
40006
5 AI
Value
Read
00107 6
Reset
Historical
Max. Value
R/W
40007
6 AI
Value
Read
00108 7
Reset
Historical
Max. Value
R/W
40008
7 AI
Value
Read
00109 Average
Ch 0 ~ 7
Reset Historical
Max. Value
R/W
40009
Average
Ch 0 ~ 7
AI Value
Read
00111 0 Reset
Historical
Min. Value
R/W 40011
0
Historical
Max. AI
Value
Read
00112 1 Reset
Historical
Min. Value
R/W 40012
1
Historical
Max. AI
Value
Read
00113 2 Reset
Historical
Min. Value
R/W 40013
2
Historical
Max. AI
Value
Read
00114 3 Reset
Historical
Min. Value
R/W 40014
3
Historical
Max. AI
Value
Read
00115 4 Reset
Historical
Min. Value
R/W 40015
4
Historical
Max. AI
Value
Read
00116 5 Reset
Historical
Min. Value
R/W 40016
5
Historical
Max. AI
Value
Read
00117 6 Reset
Historical
Min. Value
R/W 40017
6
Historical
Max. AI
Value
Read
