Response message format for function code 08:
The normal responses return the station address, function code, start
address, and requested number of coil forced.
Example: 01 0F 00 11 00 0A
Function Code 16 (10 hex)
Preset values into a sequence of holding registers.
Request message format for function code 16:
Example: Preset constant #1 (address 40009) to 100.0 in ADAM-6000
module.
01 10 00 09 00 02 04 42 C8 00 00
Response message format for function code 08:
The normal responses return the station address, function code, start
address, and requested number of registers preset.
Example: 01 10 00 09 00 02
Command Body
Station
Address
Function
Code
Start Address
High Byte
Start Address
Low Byte
Requested Number
of Coil High Byte
Requested Number
of Coil Low Byte
Command Body
Station
Address
Function
Code
Start
Address
High
Byte
Start
Address
Low Byte
Requested
Number
of Register High
Byte
Requested
Number
of Register Low
Byte
Byte
Count
Data
Command Body
Station
Address
Function
Code
Start Address
High Byte
Start Address
Low Byte
Requested Number
of Register High
Byte
Requested Number
of Register Low Byte
