ADAM-6000 Series User Manual 174
Input Condition
Stage Option Description Condition Section
NoOperation No Opeartion N/A 7.3.1
AI Local AI chan-
nel value >, =, <
DI Local DI chan-
nel value True, False
DI_Counter Local counter
input channel
value >, =, <
DI_Frequency Local fre-
quency input
channel value >, =, <
Timer Local internal
Timer value >, =, <
AuxFlag Local internal
Flag value True, False
DO Local DO
channel value True, False
Coutner Local internal
counter value >, =, <
Logic Stage Option Description Section
AND AND operation 7.3.2
OR OR operation
NAND NAND operation
NOR NOR operation
Execution Stage Option Description Section
Execution_
Period Define the
execution time
for this logic
rule 7.3.3
SendTo
NextRule Combine out-
put of this logic
rule to next
logic rule to
form Logic
Cascade
