The MDA/DH may be set from either PFD and is synchronized on both PFDs. The function is reset when the
power is cycled.
Setting the barometric minimum descent altitude and bug:
1) Select the TMR/REF Softkey.
2)
Turn the large FMS Knob to highlight the Minimums field.
3)
Turn the small FMS Knob to highlight ‘BARO’. ‘OFF’ is selected by default. Press the ENT Key or turn the large
FMS Knob to highlight the next field.
4)
Use the small FMS Knob to enter the desired altitude (from zero to 16,000 feet).
5)
To remove the window, press the CLR Key or select the TMR/REF Softkey.
Figure 2-49 Timer/References Window, MDA/DH Setting
