190-00663-01 Rev. A Garmin G1000 Pilot’s Guide for the Hawker Beechcraft C90A/GT 14
SYSTEM OVERVIEW
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL FEA
TURES
APPENDICES
INDEX
1.4 SECURE DIGITAL CARDS
NOTE: Refer to the Appendices for instructions on updating the aviation database.
NOTE: Ensure that the G1000 system is powered off before inserting the SD card.
The GDU 1040A and GDU 1500 data card slots use Secure Digital (SD) cards and are located on the top
right portion of the display bezels. Each display bezel is equipped with two SD card slots. SD cards are used
for aviation database and system software updates as well as terrain database storage. Also, flight plans may be
imported or exported from an SD card in the MFD.
Ins tall an SD card
Insert the SD card in the SD card slot, pushing the card in until the spring latch engages. The front of the card
should remain flush with the face of the display bezel.
Rem ove an SD card
Gently press on the SD card to release the spring latch and eject the card.
Figure 1-6 Display Bezel SD Card Slots
PFD MFD
SD Card Slots
1.5 SYSTEM POWER-UP
NOTE: Refer to the Appendices for AHRS initialization bank angle limitations.
NOTE: See the Appendices for additional information regarding system-specific annunciations and alerts.
