Garmin G1000 Pilot’s Guide for the Hawker Beechcraft C90A/GT 190-00663-01 Rev. A 88
ENGINE INDICATION SYSTEM
3.1 EIS DISPLAY
1 Interstage Turbine
Temperature (ITT)
Displays Interstage Turbine Temperature in degrees Celsius (°C)
2 Torque (FT-LB) Displays torque in foot-pounds
3 Tachometer (Prop RPM) Displays propeller speed in revolutions per minute (rpm); the red band
indicates propeller overspeed
4 Propeller Sync Displays a diamond when propellers are in sync. Indicates when propellers
are out of sync by the diamond transitioning to an arrowhead. The
arrowhead points towards the propeller turning at a higher-speed.
5 Turbine Speed (% RPM) Displays turbine speed in a percentage of the revolutions per minute
(rpm)
6 Fuel Flow
(FFLOW PPH)
Displays current fuel flow in pounds per hour (pph)
7 Oil Pressure (OIL PSI) Displays pressure of oil supplied to the engines in pounds per square
inch (psi)
8 Oil Temperature (OIL °C) Displays the oil temperature in degrees Celsius (°C)
