Garmin G1000 Pilot’s Guide for the Hawker Beechcraft C90A/GT 190-00663-01 Rev. A 346
HAZARD AVOIDANCE
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL FEA
TURES
APPENDICES
INDEX
Changing the viewing mode between 360˚ and 120˚:
1) Select the Stormscope Page.
2) Select the VIEW Softkey. The 360 and ARC softkeys are displayed.
3) Select the 360 Softkey to display a 360˚ viewing area or select the ARC Softkey to display a 120˚ viewing
area.
4) Select the BACK Softkey to return to the Stormscope Page.
Or :
1) Select the Stormscope Page.
2) Press the MENU Key.
3) Turn the small FMS Knob to choose between ‘View Arc’ and ‘View 360˚ options.
4) When an item is selected, press the ENT Key.
