The annunciations to indicate the status of traffic information appear in a banner at the lower left corner of
maps on which traffic can be displayed.
Traffic Status Banner
Annunciation
Description
TA OFF SCALE
A Traffic Advisory is outside the selected display
range*
Annunciation is removed when traffic comes within
the selected display range
TA X.X ± XX ↕
System cannot determine bearing of Traffic
Advisory**
Annunciation indicates distance in nm, altitude
separation in hundreds of feet, and altitude trend
arrow (climbing/descending)
TRFC FAIL
TAS unit has failed (unit is self-reporting a failure or
sending incorrectly formatted data)
NO TRFC DATA Data is not being received from the TAS unit
*Shown as symbol on Traffic Map Page
**Shown in center of Traffic Map Page
Table 6-19 TAS Traffic Status Annunciations
