ES-4024A User’s Guide
78
Chapter 7 Basic Setting
Table 12 Port Setup
LABEL
DESCRIPTION
Port
This is the port index number.
Active
Select this check box to enable a port. The factory default for all ports is enabled. A
port must be enabled for data transmission to occur.
Name
Enter a descriptive name that identifies this port.
Type
This field displays 10/100M for an Ethernet connection and 1000M for the mini-GBIC
ports.
Speed/Duplex
Select the speed and the duplex mode of the Ethernet connection on this port.
For Ethernet ports, select Auto, 10M/Half Duplex, 10M/Full Duplex, 100M/Half
Duplex, 100M/Full Duplex or 1000M/Full Duplex.
For Gigabit Ethernet/mini-GBIC ports (25 and 26), select Auto, 100M/Full Duplex or
1000M/Full Duplex.
For stacking ports (S1 and S2), select Auto or 1000M/Full Duplex.
Selecting Auto (auto-negotiation) allows one port to negotiate with a peer port
automatically to obtain the connection speed and duplex mode that both ends support.
When auto-negotiation is turned on, a port on the switch negotiates with the peer
automatically to determine the connection speed and duplex mode. If the peer port
does not support auto-negotiation or turns off this feature, the switch determines the
connection speed by detecting the signal on the cable and using half duplex mode.
When the switch’s auto-negotiation is turned off, a port uses the pre-configured speed
and duplex mode when making a connection, thus requiring you to make sure that the
settings of the peer port are the same in order to connect.
Flow Control
A concentration of traffic on a port decreases port bandwidth and overflows buffer
memory causing packet discards and frame losses. Flow Control is used to regulate
transmission of signals to match the bandwidth of the receiving port.
The ES-4024A uses IEEE802.3x flow control in full duplex mode and backpressure
flow control in half duplex mode.
IEEE802.3x flow control is used in full duplex mode to send a pause signal to the
sending port, causing it to temporarily stop sending signals when the receiving port
memory buffers fill.
Back Pressure flow control is typically used in half duplex mode to send a "collision"
signal to the sending port (mimicking a state of packet collision) causing the sending
port to temporarily stop sending signals and resend later. Select Flow Control to
enable it.
802.1P Priority This priority value is added to incoming frames without a (802.1p) priority queue tag.
See Priority Queue Assignment in
for more information.
Apply
Click Apply to save the settings.
Cancel
Click Cancel to reset the fields to your previous configuration.
