ES-4024A User’s Guide
52 Chapter 4 The Web Configurator
The following table describes the links in the navigation panel.
Link Aggregation
Link Aggregation
Protocol Status
Link Aggregation
Port Authentication
RADIUS
802.1x
Port Security
DHCP
IP Table
ARP Table
Routing Table
DHCP Server Status
Access Control
SNMP
Logins
Service Access
Control
Remote
Management
Classifier
DiffServ
DSCP Setting
Marking Rule Setting
Queuing Method
VRRP
Status
VRRP Configuration
Table 5 Navigation Panel Links
LINK DESCRIPTION
Basic Settings
System Info This link takes you to a screen that displays general system and hardware
monitoring information.
General Setup This link takes you to a screen where you can configure general identification
information about the switch.
Switch Setup This link takes you to a screen where you can set up global switch parameters such
as VLAN type, MAC address learning, IGMP snooping, GARP and priority queues.
IP Setup This link takes you to a screen where you can configure the IP address, subnet
mask (necessary for switch management) and DNS (domain name server) and set
up to 64 IP routing domains.
Port Setup This link takes you to screens where you can configure settings for individual switch
ports.
Advanced
Application
Table 4 Web Configurator Screen Sub-links Details
BASIC SETTING
ADVANCED
APPLICATION
ROUTING PROTOCOL MANAGEMENT
