ES-4024A User’s Guide
238 Chapter 38 Command Examples
Figure 151 filter Command Example
38.7.4 mirror
Syntax:
mirror classifier
mirror-port
where
This command sets the switch to copy the incoming/outgoing traffic flow defined by a
classifier to the specified mirror port.
An example is shown next.
• Create a classifier to define all IP traffic in VLAN 1 from port 3 to the destination device
with a MAC address of 00:a0:c5:00:00:01.
• Enable mirroring on the classifier.
• Enable the monitor port three.
Figure 152 mirror Command Example
38.7.5 gvrp
Syntax:
gvrp
GVRP (GARP VLAN Registration Protocol) is a registration protocol that defines a way for
switches to register necessary VLAN members on ports across the network. Enable this
function to permit VLANs groups beyond the local switch.
An example is shown next.
• Enable the IEEE 802.1Q tagged VLAN command to configure tagged VLAN for the
switch.
ras(config)# classifier Example ethernet-type ip vlan 1 source-port 3
destination-mac 00:a0:c5:00:00:01
ras(config)# filter classifier Example
Specifies the name of the classifier to which this rule applies.
This is the mirror port number.
ras(config)# mirror classifier Example
ras(config)# mirror-port 3
