ES-4024A User’s Guide
Chapter 20 Classifier
135
Port
Select the port to which the rule should be applied. You may choose one port only
or all ports (All Ports).
Destination
MAC Address
Select Any to apply the rule to all MAC addresses.
To specify a destination, select the second choice and type a MAC address in
valid MAC address format (six hexadecimal character pairs).
Port
Select the port to which the rule should be applied. You may choose one port only
or all ports (All Ports).
Layer 3
Specify the fields below to configure a layer 3 classifier.
IP Protocol
Select an IP protocol type or select Other and enter the protocol number in
decimal value. Refer to
for more information.
You may select Establish Only for TCP protocol type. This means that the switch
will pick out the packets that are sent to establish TCP connections.
Source
IP Address/
Address Prefix
Enter a source IP address in dotted decimal notation.
Specify the address prefix by entering the number of ones in the subnet mask.
Socket Number
Note: You must select either UDP or TCP in the IP Protocol field
before you configure the socket numbers.
Select Any to apply the rule to all TCP/UDP protocol port numbers or select the
second option and enter a TCP/UDP protocol port number.
Destination
IP Address/
Address Prefix
Enter a destination IP address in dotted decimal notation.
Specify the address prefix by entering the number of ones in the subnet mask.
Socket Number
Note: You must select either UDP or TCP in the IP Protocol field
before you configure the socket numbers.
Select Any to apply the rule to all TCP/UDP protocol port numbers or select the
second option and enter a TCP/UDP protocol port number.
Add
Click Add to insert the entry in the summary table below.
Cancel Click
Cancel to reset the fields back to your previous configuration.
Clear Click
Clear to set the above fields back to the factory defaults.
Index
This field displays the index number of the rule. Click an index number to edit the
rule.
Active
This field displays Yes when the rule is activated and No when is it deactivated.
Name
This field displays the descriptive name for this rule. This is for identification
purpose only.
Rule
This field displays a summary of the classifier rule’s settings.
Delete
Click Delete to remove the selected entry from the summary table.
Cancel
Click Cancel to clear the Delete check boxes.
Table 44 Classifier (continued)
LABEL
DESCRIPTION
