ES-4024A User’s Guide
108 Chapter 15 Link Aggregation
• You must connect all ports point-to-point to the same Ethernet switch and configure the
ports for LACP trunking.
• LACP only works on full-duplex links.
• All ports in the same trunk group must have the same media type, speed, duplex mode
and flow control settings.
Configure trunk groups or LACP before you connect the Ethernet switch to avoid causing
network topology loops.
15.1.2 Link Aggregation ID
LACP aggregation ID consists of the following information
1
:
15.2 Link Aggregation Status
Click Advanced Application, Link Aggregation in the navigation panel. The Link
Aggregation Control Protocol Status screen displays by default.
Table 28 Link Aggregation ID: Local Switch
SYSTEM PRIORITY MAC ADDRESS KEY PORT PRIORITY PORT NUMBER
0000 00-00-00-00-00 0000 00 0000
Table 29 Link Aggregation ID: Peer Switch
SYSTEM PRIORITY MAC ADDRESS KEY PORT PRIORITY PORT NUMBER
0000 00-00-00-00-00 0000 00 0000
1. Port Priority and Port Number are 0 as it is the aggregator ID for the trunk group, not the individual
port.
