ES-4024A User’s Guide
Chapter 28 OSPF 171
Figure 101 OSPF Configuration: Activating and General Settings
The follow table describes the related labels in this screen.
Table 65 OSPF Configuration: Activating and General Settings
LABEL DESCRIPTION
Active OSPF is disabled by default. Select this option to enable it.
Router ID Router ID uniquely identifies the ES-4024A in an OSPF. Enter a unique ID (that uses the
format of an IP address in dotted decimal notation) for the ES-4024A.
Redistribute
Route
Route redistribution allows your ES-4024A to import and translate external routes
learned through other routing protocols (RIP and Static) into the OSPF network
transparently.
Active Select this option to activate route redistribution for routes learn through the selected
protocol.
Type Select 1 for routing protocols (such as RIP) whose external metrics are directly
comparable to the internal OSPF cost. When selecting a path, the internal OSPF cost is
added to the AB boundary router to the external metrics.
Select 2 for routing protocols whose external metrics are not comparable to the OSPF
cost. In this case, the external cost of the AB boundary router is used in path decision to
a destination.
Metric Value Enter a route cost (between 0 and 16777214).
Apply Click Apply to save the changes.
Cancel Click Cancel to start configuring the above fields again.
