ES-4024A User’s Guide
Chapter 6 System Status and Port Statistics 65
Figure 28 Status: Port Details
The following table describes the labels in this screen.
Table 7 Status: Port Details
LABEL DESCRIPTION
Port Info
Link This field shows whether the Ethernet connection is down, and the speed/duplex
mode.
Status This field shows the training state of the ports. The states are FORWARDING
(forwarding), which means the link is functioning normally or STOP (the port is stopped
to break a loop or duplicate path).
LACP This field shows if LACP is enabled on this port or not.
TxPkts This field shows the number of transmitted frames on this port
RxPkts This field shows the number of received frames on this port
Errors This field shows the number of received errors on this port.
Tx KB/s This field shows the number kilobytes per second transmitted on this port.
