ES-4024A User’s Guide
106 Chapter 14 Mirroring
Table 26 Mirroring: Mirror Port Setting
LABEL DESCRIPTION
Active Clear this check box to deactivate port mirroring on the switch.
Mirror Port The mirror port is the port you copy the traffic to in order to examine it in more detail
without interfering with the traffic flow on the original port(s). Select this port from this
drop-down list box.
Apply Click Apply to save the changes.
Cancel Click Cancel to start configuring the screen again.
Active Make sure to select this check box to activate your rule. You may temporarily deactivate a
rule without deleting it by deselecting this check box.
Name This read-only field displays the name of the classifier you select in the Classifier field.
Classifier A classifier groups traffic flow based on the specified criteria. This field displays the
name(s) of the classifier(s) you configure in the Classifier screen.
Select a classifier to which the rule is to apply. Traffic flow (both incoming or outgoing) that
matches the criteria of the classifier will be copied to the specified mirror port.
Add Click Add to inset the entry to the summary table below.
Cancel Click Cancel to reset the fields to your previous configuration.
Clear Click Clear to set the above fields back to the factory defaults.
Index This field displays the index number of a rule. Click this number to edit the rule settings.
Active This field indicates whether the rule is enabled (Yes) or disabled ( No )
Name This field displays the descriptive name of the rule.
Classifier This field displays the name of the classifier to which this rule applies.
Delete Click Delete to remove the selected entry from the summary table.
Cancel Click Cancel to clear the Delete check box(es).
