ES-4024A User’s Guide
Chapter 4 The Web Configurator
53
VLAN
This link takes you to screens where you can configure port-based or 802.1Q VLAN
(depending on what you configured in the Switch Setup menu).
Static MAC
Forwarding
This link takes you to screens where you can configure static MAC addresses for a
port. These static MAC addresses do not age out.
Filtering
This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure the STP/RSTP to prevent
network loops.
Bandwidth
Control
This link takes you to screens where you can cap the maximum bandwidth allowed
from specified source(s) to specified destination(s).
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring
This link takes you to screens where you can copy traffic from one port or ports to
another port in order that you can examine the traffic from the first port without
interference
Link Aggregation This link takes you to a screen where you can logically aggregate physical links to
form one logical, higher-bandwidth link.
Port
Authentication
This link takes you to a screen where you can configure RADIUS (Remote
Authentication Dial-In User Service), a protocol for user authentication that allows
you to use an external server to validate an unlimited number of users.
Port Security
This link takes you to a screen where you can activate MAC address learning and
set the maximum number of MAC addresses to learn on a port.
DHCP
This link takes you to a screen where you can configure the DHCP settings for the
network on the ES-4024A.
Access Control
This link takes you to screens where you can change the system login password
and configure SNMP and remote management.
Classifier
This link takes you to a screen where you can configure the switch to group packets
based on the specified criteria.
DiffServ
This link takes you to screens where you can enable DiffServ, configure marking
rules and set DSCP-to-IEEE802.1p mappings.
Queuing Method This link takes you to a screen where you can configure SPQ or WFQ with
associated queue weights for each port.
VRRP
This link takes you to screens where you can configure redundant virtual router for
your network.
Routing Protocol
Static Route
This link takes you to screens where you can configure static routes. A static route
defines how the ES-4024A should forward traffic by configuring the TCP/IP
parameters manually.
RIP
This link takes you to a screen where you can configure the RIP (Routing
Information Protocol) direction and versions.
IGMP
This link takes you to a screen where you can configure the IGMP settings.
DVMRP
This link takes you to a screen where you can configure the DVMRP (Distance
Vector Multicast Routing Protocol) settings.
OSPF
This link takes you to screens where you can view the OSPF status and configure
OSPF settings.
Advanced
Management
Table 5 Navigation Panel Links (continued)
LINK
DESCRIPTION
