ES-4024A User’s Guide
Chapter 31 Cluster Management 185
C
H A P T E R
31
Cluster Management
This chapter introduces cluster management.
31.1 Overview
Cluster Management allows you to manage switches through one switch, called the cluster
manager. The switches must be directly connected and be in the same VLAN group so as to be
able to communicate with one another.
In the following example, switch A in the basement is the cluster manager and the other
switches on the upper floors of the building are cluster members.
Figure 115 Clustering Application Example
Table 72 ZyXEL Clustering Management Specifications
Maximum number of cluster members 24
Cluster Member Models Must be compatible with ZyXEL cluster management
implementation.
Cluster Manager The switch through which you manage the cluster member
switches.
Cluster Members The switches being managed by the cluster manager switch.
