6287 ALLY PLUS User’s Manual Page 5-4
Function Options
The following table describes all valid non-zero values in a function table.
A function value of zero (00) in the table indicates a one-for-one translation
of a source character to a printable character. A non-zero value has special
meaning. Note that an asterisk (*) indicates that the function is applied only
when rows and columns are being counted (i.e., when Option #70 —
DisplayWrite 370 is enabled). Items in italics apply only to the ASCII from
ASCII table when programming the unit from an alternate host.
Value Meaning
01 End of message
*
02 Send a form feed and clear the line count
*
03 Send new line and clear column count
*
04 Vertical channel select (SCS only)
*
or ASCII hex data
05 Send CR and clear column count
*
06 Treated as null or ASCII numeral
07 Bell character (see Option #75)
08 Move left one space in print buffer
*
09 Tab right to next tab stop
*
0A Send line feed and add to line count
*
0B Send line feeds until next vertical tab stop
*
0C — reserved for future use —
0D — reserved for future use —
0E Add to line count
*
0F — reserved for future use —
10 Escape handler (SCS 2Bxx) or ASCII semicolon (;)
11 — reserved for future use —
12 Pseudo transparency trigger
13 — reserved for future use —
14 Graphic escape (SCS only)
15 IBM 35h transparency trigger (SCS only)
16 Xerox 36h transparency trigger (SCS only)
17 — reserved for future use —
18 Display field switch ON
19 Display field switch OFF or ASCII asterisk (*)
1A Character is ignored or ASCII dollar sign ($)
1B UDK trigger or ASCII Y/N
1C Xerox font trigger (‘i’)
1D UDK definition trigger (‘=’)
1E ALLY PLUS program mode trigger (‘!’)
1F Pass character w/o translation or ASCII percent sign (%)
