6287 ALLY PLUS User’s Manual Page 6-2
VTAM and Network Control Program
Requirements
The 3174, 3274 or 3276 control unit to which the ALLY PLUS is attached
must be defined as a type 2 physical unit and the logical unit (type 1 or 3)
definition must be included for each ALLY PLUS to be attached. The
following is an example of log mode entry tables for DSC and SCS that
may be used with the ALLY PLUS. If necessary, consult with the Company
System Manager regarding specific requirements for the system,
environment and applications.
DSC2K MODEENTLOGMODE=DSC2K
BIND USED FOR APPLICATION SESSIONS
FMPROF=X‘03' FUNCTION MANAGEMENT PROFILE
TSPROF=X‘03' TRANSMISSION SERVICES PROFILE
PRIPROT=X‘B1' PRIMARY PROTOCOL
SECPROT=X‘90' SECONDARY PROTOCOL
COMPROT=X‘3080' COMMON PROTOCOL
RUSIZES=X‘8787' PRI RUSIZE=1024, SEC RUSIZE=1024
PSERVIC=X‘030000000000185018507F00'
LU SERVICES PROFILE
SCS MODEENT LOGMODE=SCS
BIND USED FOR APPLICATION SESSIONS
FMPROF=X‘03' FUNCTION MANAGEMENT PROFILE
TSPROF=X‘03' TRANSMISSION SERVICES PROFILE
PRIPROT=X‘B1' PRIMARY PROTOCOL
SECPROT=X‘90' SECONDARY PROTOCOL
COMPROT=X‘3080' COMMON PROTOCOL
RUSIZES=X‘87C6' PRI RUSIZE-768, SEC RUSIZE=1024
PSNDPAC=X‘01' PRIMARY SEND PACING COUNT
SRCVPAC=X‘01' SECONDARY RECEIVE PACING COUNT
PSERVIC=X‘01000000E100000000000000'
LU SERVICES PROFILE
APL Support
When using APL, the log mode entry tables above will be the same except
for the last line, “PSERVIC=X' .” In DSC, a change must be made to the
byte following the “X'03.” In SCS, a change must be made to the byte
following the “X'01.” The second byte (00) must be changed to another
value, depending upon the device for which the user’s application was
written. The following table indicates the appropriate replacement value.
