APPENDIX
General Information
The Appendix contains samples of the General Configuration Report,
Programmable Function String Report, Translate and Function Table
Report, Printer Test, Plotter Test, Host Diagnostic Report, a Hexadecimal to
Decimal Conversion Chart and a Pin-out chart of the ALLY PLUS ports.
General Configuration Report
The following is a sample of the General Configuration Report with the
factory defaults selected. Options that are not factory defaults would be
preceded by an asterisk (*) in an actual report. Use Mode 5 from the front
panel of the ALLY PLUS to send the printer a report of the current general
configuration.
SECTION 12
