INSTALLATION
General Information
This chapter provides information on physically attaching the AGILE 6287
ALLY PLUS to the computer environment.
Before Beginning
The following are needed before installing the ALLY PLUS:
• A suitable location.
• A serial or parallel printer (or plotter).
• A host interface cable — RG62 A/U coaxial cable with BNC
connectors on both ends. The length of this cable is not to exceed
5000 feet (1500 meters).
• Additionally, the user or someone in the user’s organization should
be knowledgeable about the host system.
Selecting a Location
The compact size, quiet operation and attractive styling of the ALLY PLUS
enable it to be placed in almost any location. For ease of operation, it is best
installed beside the printer.
Space Requirements
The dimensions of the ALLY PLUS are as follows:
SECTION 2
