Page 7-3 SCS DATA STREAMS
Interchange Group Separator (IGS) — 1Dh
The ALLY PLUS interprets this Interchange Separator as a space.
Interchange Record Separator (IRS) — 1Eh
The ALLY PLUS interprets this Interchange Separator as a new line.
Interchange Unit Separator (IUS) — 1Fh
The ALLY PLUS interprets this Interchange Separator as a space.
Line Feed (LF) — 25h
The Line Feed command moves the presentation position down to the next
line. The column position remains the same. Option #15 (SCS line spacing)
may cause the ALLY PLUS to move down more than one line.
Null — 00h
The Null command is converted to a space by the ALLY PLUS.
Set Horizontal Format (SHF) — 2BC1h
The Set Horizontal Format command is used to set left and right margins,
horizontal tab stops that are used by the horizontal tab command, and to set
the maximum presentation position for the page.
Note: The SHF command will override the configuration settings of Options
11 and 12.
The SHF command has multiple parameters in the following format:
(SHF)(CNT)(MPP)(LM)(RM)(T1)...(TN) Where:
SHF The Set Horizontal Format command code = 2BC1h
CNT A Count of the number of bytes in this command string,
including the count byte.
MPP The maximum width of the print line. Default is the line
length of the physical device.
LM The character position of the Left Margin. LM is also the first
horizontal tab stop. The LM value must be less than or equal
to MPP. The default is 1.
