Page 3-7

CONFIGURATION

03 — Plotter support

Mode 9 on the front panel of the ALLY PLUS will produce four tests on the

attached plotter that verify baud rate, protocol, etc. For these tests to

function correctly, select the appropriate plotter from the list below. When

programming this option, use one of these sequences:

!ALLY!03=01;

for HP 7221 plotter attachment

!ALLY!03=02;

for HP 7475 plotter attachment

!ALLY!03=03;

for HP 7550 plotter attachment (default)

!ALLY!03=04;

for Zeta GML plotter attachment

05 — Plotter support

Mode 9 on the front panel of the ALLY PLUS will produce four tests on the

attached plotter that verify baud rate, protocol, etc. For these tests to

function correctly, select the appropriate plotter from the list below. When

programming this option, use one of these sequences:

!ALLY!03=01;

for HP 7221 plotter attachment

!ALLY!03=02;

for HP 7475 plotter attachment

!ALLY!03=03;

for HP 7550 plotter attachment (default)

!ALLY!03=04;

for Zeta GML plotter attachment
