6287 ALLY PLUS User’s Manual Page 12-4
Programmable Function String Report
These three pages contain sample Programmable Function String Reports.
Use Mode 7 from the front panel of the ALLY PLUS to send a report of the
current PFS configuration.
The PFS values shown on this page are for a Xerox type printer (Choice 00
in General Configuration Option #00). If the user has selected “None” for
printer type in Option #00 (Choice 03, the default), and if the user has not
defined any PFSs, the report will not print, because no PFSs have been
defined.
Note: The comments to the right are translations of the hexadecimal values;
they are not printed in the actual report.
AGILE 6287 ALLY PLUS Version 6.00, Style 1 10-02-1995
(c) 1995 by AGILE. All rights reserved.
Programmable Function String Report Page 1
PFS %00 Power On
1B 2B 58 0D 0A
s+X CR LF
PFS %01 Printer Reset
1B 2B 58 0D 0A
s+X CR LF
PFS %02 Bolding On
1B 62
sb
PFS %03 Bolding Off
1B 70
sp
PFS %04 Overstriking On
1B 7A 6F 00
szo [null]
PFS %05 Overstriking Off
1B 7A 70
szp
PFS %06 Underlining On
1B 75
su
PFS %07 Underlining Off
1B 77
sw
