6287 ALLY PLUS User’s Manual Page 2-8
5 — General Configuration Report
The ALLY PLUS will return to normal operating mode after a General
Configuration Report is sent to the current printer. (See the Appendix for a
sample of this report.)
6 — Translate Table Report
The ALLY PLUS will return to normal operating mode after a Translate
Table and Function Report is sent to the current printer. (See the Appendix
for a sample report.)
7 — PFS Report
The ALLY PLUS will return to normal operating mode after a PFS Report
is sent to the current printer. (See the Appendix for a sample report.)
8 — Printer Test Report
This mode tests the connection between the ALLY PLUS and the current
printer. It sends out a continuous stream of characters, including alphabetic,
numeric and special characters. (See Appendix.) The ALLY PLUS must be
powered down to stop this operation.
9 — Plotter Test Report
This mode tests the connection between the ALLY PLUS and the current
plotter. (See Appendix.) Any plotter capable of accepting GML or HPGL
plot commands may be tested with this selection. (See Section 3 —
Configuration, and use Option #03 for selecting the plotter to be tested.)
A — ASCII/EBCDIC Toggle
The ALLY PLUS will return to normal operating mode after switching
from the current selection (ASCII or EBCDIC) to the other (EBCDIC or
ASCII). All data will be output in the new data format until the ALLY
PLUS is configured otherwise. This option also can be configured from the
host (see Section 3 — Configuration).
B — Serial Port Mode
The ALLY PLUS will return to normal operating mode after switching to
serial output. All output from the ALLY PLUS will come from the SERIAL
1 port until configured otherwise. This option also can be configured from
the host (see Section 3 — Configuration).
