Chapter 1 – Product Description and Specifications

Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)

8

Specifications

Category

Description

Memory

8 MEG

Flash Memory

2 MEG

Protocols Supported

ARP, DHCP, FTP, HTTP, ICMP, IP, POP3, PPP, SMTP, TCP, Telnet,
TFTP, and UDP

Serial Interface

Standard DCE serial

Data Formats

Serial, binary, asynchronous

Data Rates

300; 1200; 2400; 4800; 9600; 19200; 38400; 57600; 115200; 230400 bps

Flow Control

RTS/CTS (hardware)

Management

Serial; Telnet

Security

Username and password authentication using local database

System Software

Flash ROM standard: downloadable from a TCP/IP host (TFTP) or
Xmodem via Serial

LEDs

ACT (Activity) and STS (Status)

Ethernet

IEEE 802.3

Power Requirements

With External Power (MTS2SA-T) Power Consumption

@ 9V DC:

Typical 240mA

Maximum 250mA

With RS-232 Power (MTS2SA-T-R) Power Consumption

@ 5V DC:

Typical 95mA

Maximum 105mA

@ 10V DC:

Typical 50mA

Maximum 60mA

@ 15V DC:

Typical 35mA

Maximum 45mA

@ 20V DC:

Typical 28mA

Maximum 38mA

@ 25V DC:

Typical 24mA

Maximum 34mA

Operating Temperature

32

° to +120°F (0° to 50°C); humidity range 25-85% (non-condensing)

Storage Temperature

-40

°C to +85°C

Physical Dimensions

3.5" w x 2.1" h x 0.98" d; 3.4 oz.
8.8 cm x 5.3 cm x 6 cm; 96 g

Certifications

Safety Certifications:

UL60950
cUL60950
EN60950
ACA TS001 / AS 3260

EMC Safety Approvals:

FCC Part 15 Class A
EN55022
EN55024

CE Marked
