Chapter 10

− Modem Mode AT Commands, S-Registers, and Result Codes

Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)

113

Example Modem Response and Usage

Example #UD commend response are shown in Table 8-11.

Table 8-11. Completed Data Call, with some errors and rate retrain during the call

Modem Response Line

Description

DIAG <2A4D3263 0=09>

This is version 0.9

DIAG <2A4D3263 1=06 2=0 3=0>

Data Answer signal detected; Data only;
Character async

DIAG <2A4D3263 5=”C14513902A”
6=”A145”>

V.8 Call Menu indicates:
V.8 Joint Menu selects:

DIAG <2A4D3263 10=1F 11=0C 12=52>

Receive level = -31 dBm; transmit level = -12 dBm;
noise level = -82 dBm

DIAG <2A4D3263 14=03 15=05 16=10>

Far end echo delay in milliseconds;
Far end echo loss in dB;
Near end echo loss = 16 dB

DIAG <2A4D3263 20=C 22=780 24=0C80
26=79E0>

Transmitter: V.34 training completed;
V.34 carrier frequency = 1920; V.34
symbol rate = 3200; initial transmit rate is 31200 bit/s

DIAG <2A4D3263 21=D 25=1F40 27=DAC0>

Receiver: V.90 training completed;
V.90 symbol rate = 8000;
initial receive rate is 56000 bit/s

DIAG <2A4D3263 30=00 31=03 32=01
33=01>

No carrier loss events, 3 carrier rate renegotiations
attempted;
1 carrier retrain requested;
1 carrier retrain granted

DIAG <2A4D3263 34=7080 35=CB20>

Final transmit rate is 28800 bit/s;
final receive rate is 52000 bit/s

DIAG <2A4D3263 40=1 41=100>

LAPM negotiation completed; frame size = 256

DIAG <2A4D3263 42=0 43=0>

No error control timeout or link NAKs

DIAG <2A4D3263 44=1 45=400>

V.42bis data compression used;
dictionary size = 1024

DIAG <2A4D3263 50=2 51=2>

Hardware transmit and receive flow control

DIAG <2A4D3263 52=343CC 54=0>

213964 DTE characters transmitted, w/o underrun

DIAG <2A4D3263 53=7230E6 55=47>

7483622 DTE characters received, 71 characters lost
due to receive data overrun

DIAG <2A4D3263 56=29D 58=0001>

597 (decimal) frames transmitted, with 1 frame error

DIAG <2A4D3263 58=2A4B 59=0004>

10827 (decimal) frames received, with 4 frame errors

DIAG <2A4D3263 60=51>

Local PC initiated hangup



Command:

+++ Escape Sequence

Values: n/a
Description:

When the modem has established a connection and has entered online data mode, it is
possible to break into the data transmission in order to issue further commands to the
modem in an online command mode. This is achieved by the DTE sending to the modem a
sequence of three ASCII characters specified by register S2. The default character is +. The
maximum time allowed between receipt of the last character of the three escape character
sequence from the DTE and sending of the OK result code to the DTE is controlled by the
S12 register.
