Chapter 10

− Modem Mode AT Commands, S-Registers, and Result Codes

Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)

128

Short
Form

Long Form

Description

11 CONNECT

4800

Connected at 4800 bps

and speed reporting enabled. The modem has connected to

the line, the DTE speed is 4800 bps and DTE speed reporting is enabled.

12 CONNECT

9600

Connected at 9600 bps and speed reporting enabled.

The modem has connected to

the line, the DTE speed is 9600 bps and DTE speed reporting is enabled.

13 CONNECT

7200

Connected at 7200 bps and speed reporting enabled.

The modem has connected to

the line, the DTE speed is 7200 bps and DTE speed reporting is enabled.

14 CONNECT

12000

Connected at 12000 bps and speed reporting enabled.

The modem has connected to

the line the DTE speed is 12000 bps and DTE speed reporting is enabled.

15 CONNECT

14400

Connected at 14400 bps and speed reporting enabled.

The modem has connected to

the line, the DTE speed is 14400 bps and DTE speed reporting is enabled.

16 CONNECT

19200

Connected at 19200 bps and speed reporting enabled.

The modem has connected to

the line, the DTE speed is 19200 bps and DTE speed reporting is enabled.

17 *

CONNECT
38400

Connected at 38400 bps and speed reporting enabled.

The modem has connected to

the line, the DTE speed is 38400 bps and DTE speed reporting is enabled.

18 *

CONNECT
57600

Connected at 57600 bps and speed reporting enabled.

The modem has connected to

the line, the DTE speed is 57600 bps and DTE speed reporting is enabled.

19 *

CONNECT
115200

Connected at 115200 bps and speed reporting enabled.

The modem has connected

to the line, the DTE speed is 115200 bps and DTE speed reporting is enabled.

20 *

CONNECT
230400

Connected at 230400 bps and speed reporting enabled.

The modem has connected

to the line, the DTE speed is 230400 bps and DTE speed reporting is enabled.

22 CONNECT

75TX/1200RX

V.23 connection and line speed reporting enabled.

The modem has established a

V.23 originate connection and line speed reporting is enabled.

23 CONNECT

1200TX/75RX

V.23 connection and line speed reporting enabled.

The modem has established a

V.23 answer connection and line speed reporting is enabled.

24 DELAYED Delay is in effect for the dialed number. For X4, sent when a call fails to connect and

the number dialed is considered 'delayed' due to country blacklisting requirements.

32 BLACKLISTED

Dialed number is blacklisted.

For X4, sent when a call fails to connect and the number

dialed is considered 'blacklisted'.

33 *

FAX

Connected in fax mode.

Modem connection is established in a facsimile mode.

35 *

DATA

Connected in data mode.

Modem connection is established in a data mode.

40 *

+MRR: 300

Connected at 300 bps and carrier reporting enabled.

Modem connects to the line at

300 bps and carrier reporting is enabled. (See S95 and Xn.)

44 *

+MRR:
1200/75

V.23 backward channel.

V.23 backward channel carrier is detected; carrier reporting is

enabled. (See S95, Xn.)

45 *

+MRR:
75/1200

V.23 forward channel.

V.23 forward channel carrier is detected; carrier reporting is

enabled. (See S95, Xn.)

46 *

+MRR: 1200

Connected at 1200 bps and carrier reporting enabled.

Modem connects to the line at

1200 bps and carrier reporting is enabled. (See S95, Xn.)

47 *

+MRR: 2400

Connected at 2400 bps and carrier reporting enabled.

Modem connects to the line at

2400 bps and carrier reporting is enabled. (See S95, Xn.)

48 *

+MRR: 4800

Connected at 4800 bps and carrier reporting enabled.

Modem connects to the line at

4800 bps and carrier reporting is enabled. (See S95, Xn.)

49 *

+MRR: 7200

Connected at 7200 bps and carrier reporting enabled.

Modem connects to the line at

7200 bps and carrier reporting is enabled. (See S95, Xn.)

50 *

+MRR: 9600

Connected at 9600 bps and carrier reporting enabled.

Modem connects to the line at

9600 bps and carrier reporting is enabled. (See S95, Xn.)

51 *

+MRR: 12000

Connected at 12000 bps and carrier reporting enabled.

Modem connects to the line

at12000 bps; carrier reporting is enabled. (See S95, Xn.)

52 *

+MRR: 14400

Connected at 14400 bps and carrier reporting enabled.

Modem connects to the line

at 14400 bps; carrier reporting is enabled. (See S95, Xn.)

53 *

+MRR: 16800

Connected at 16800 bps and carrier reporting enabled.

Modem connects to the line

at 16800 bps; carrier reporting is enabled. (See S95, Xn.)

54 *

+MRR: 19200

Connected at 19200 bps and carrier reporting enabled.

Modem connects to the line

at 19200 bps; carrier reporting is enabled. (See S95, Xn.)

55 *

+MRR: 21600

Connected at 21600 bps and carrier reporting enabled.

Modem connects to the line

at 21600 bps; carrier reporting is enabled. (See S95, Xn.)

56 *

+MRR: 24000

Connected at 24000 bps and carrier reporting enabled.

Modem connects to the line

at 24000 bps; carrier reporting is enabled. (See S95, Xn.)

57 *

+MRR: 26400

Connected at 26400 bps and carrier reporting enabled.

Modem connects to the line

at 26400 bps; carrier reporting is enabled. (See S95, Xn.)

58 *

+MRR: 28800

Connected at 28800 bps and carrier reporting enabled.

Modem connects to the line

at 28800 bps; carrier reporting is enabled. (See S95, Xn.)
