Chapter 1 – Product Description and Specifications

Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)

7

Types of Adapters Available

Product Adapter

Description

Region

MTS2SA-T

Serial-to-Serial + IP (External Power)

Global

MTS2SA-T-R

Serial-to-Serial + IP (RS-232 Power)

Global

Note:

The RS-232–powered adapters are powered through the DSR pin of the

RS-232 cable.

Package Contents

One MultiConnect Adapter

One universal power supply with power cord included with the externally powered adapters

One RS-232 cable included with the RS-232 Serial-to-Serial Adapter

Two mounting brackets

Four adhesive-backed rubber feet (table-top mounting)

One Quick Start Guide

One MultiConnect CD

Handling Precautions

All devices must be handled with certain precautions to avoid damage due to the accumulation of static
charge. Although input protection circuitry has been incorporated into the devices to minimize the effect of
this static buildup, proper precautions should be taken to avoid exposure to electrostatic discharge during
handling and mounting.
