Chapter 12 – HTTP Server
Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)
140
The Embedded HTML Page
The embedded Web page stored on the MultiConnect IP consists of normal ASCII text HTML
code, which can be generated using any HTML editing tool. The page can include scripts, links to
remote Web sites, graphic images, text files, etc.
A maximum 30 KB (uncompressed) of flash space for the OEM’s Home Page and an additional
10 KB maximum memory is reserved for the device parameter list.
The OEM Web page must contain the Parameter Tags, which are the placeholders in HTML
files. These tags are replaced on the fly with real-time values when the page is sent to the
browser. The value of the parameter tags also can be changed through the browser in order to
configure the host through the MultiConnect IP.
The developer should ensure that the parameter values, which are to be replaced, are qualified
with %P
Example:
--
--
--
--
Efficiency %P1%
">
--
--
In the above sample code segment, when the browser requests a page, the
%P1%
is replaced
with Parameter P1's value. This value is extracted from the serial device parameter file.
CGI Scripts
•
Post-Query is a built-in CGI script that will parse the new values set by the browser and
replace them in the http-host-param file. See the section entitled Parameters Manipulation
from the Browser for more technical information about the Post-Query CGI script.
•
The MultiConnect IP supports a user-defined CGI script, which performs host-specific
processing to the parameters configured by the remote Web browser.
Important:
The user-defined CGI-script
MUST
be a shell script.
File Naming and File Size Conventions
The following file naming conventions and file size constraints must be followed by the OEM Web
page developer.
File Name(s)
Description
http-s0.HTML
Serial Device Main Page
http-host-param
Default Serial Device Parameter List
http-*.HTML
Any HTML file, should have the filename prefixed with "http-"
cgi-*
Any cgi script should have the filename prefixed with "cgi-"
Constraints
The HTML file size cannot exceed 30KB Max.
The Parameter list file cannot exceed 10KB Max.
The Parameter tags
The URL for
Host Configuration
is http-s0.HTML. Therefore, the main page must have the filename
http-s0.HTML when the host device's HTML page is uploaded to the MultiConnect IP.
