Chapter 12 – HTTP Server

Multi-Tech Systems, Inc. MultiConnect Serial-to-Serial Adapter User Guide (S000354A)

139

Example:

P0:temperature:I:1:65535:100
P1:username:S:8:50:MultiConnect IP

Here, P0 and P1 are two parameters, which correspond to the names like Temperature &
username specified in the HTML page.

I/S represents Integer and String respectively.
1 is the minimum value for the parameter P0
65535 is the maximum value for the parameter P0.

8 is the minimum number of characters for the parameter P1.
50 is the maximum number of characters for the parameter P1.

100: in P0 is an integer Data
MultiConnect IP: in P1 is a string Data.

The serial device parameter list file (http-host-param) for the demo Web page, which is included with the
default setup, (see Figure 3) uses the following parameters and values:

P0:UPSstatus:S:0:5:ON
P1:Efficiency:I:0:100:90
P2:NoiseLevel:I:0:100:5
P3:OverloadCapacity:I:0:100:89
P4:Tolerance:I:0:100:90
P5:InputCurrent:I:0:100:78
P6:InputLineVoltage:I:0:100:90
P7:OutputVoltage:I:0:100:45
P8:BatteryVoltage:I:0:100:78
P9:Load:S:0:100:90
P10:Alarm:S:0:10:silence
